VS-1

Request A Quote →

PRODUCT ADVANTAGES

5.5-inch color touch LCD screer guickly capture the pupil.completing the test within 1 second.

1 meter test distance.completing binocular vision screening simultaneously.

Portable to carry with weight less than 800gram.

Wide Measuring Range

Detect refractive abnormalities such as pupil sizes anisometropiastrabismus lamblyopia,etc

Efficient & Portable Data Storage

It supports 4G network and is equipped with multiple data transmission interfaces,which can realize large-scale continuous screening

Long Endurance,Fast Charging

Low-power consumption.large-capacity battery can realize 8 hours of continuous operation of the device, support QC3.0 fast charge.

Efficient & Portable Data Storage

 It supports 4G network and is equipped with multiple data transmission interfaces,which can realize large-scale continuous screening

A I

GPU parallel computer hardware  architecture supporting deep learning technology and seamlessly connecting with third-party Al platforms.


TECHNICAL PARAMETER

Age Range: >6 months child and adult

Measuring Distance: 100cm Accuracy:±5cm

DS   Range:-7.50D~+7.5OD Resolution: 0.25D Accuracy: ±0.50D

DC   Range:0~-3.00DResolution: 0.25D Accuracy: ±0.50D

Axis  Range:0°~180°Resolution: 1° Accuracy: ±5°

Pupil Diameter: Range:4.0mm~9.00mm Resolution: 0.1mm Accuracy: ±5

Pupil DistanceRange: 35mm~80mm Resolution: 0.1mm Accuracy: +1mm

Time Per measurement: <0.5s

Data Transmission: USB3.0WIFIBluetoothSD,HDMIType-C

Display Screen: 5.5 Inch touch screen

Endurance Time: >8Hours

Charging Time: <3 Hours

Net Weight<800g
